MRCOOL® Universal Series 2–3 Ton DC Inverter Heat Pump Condenser – Up to 20 SEER, Ultra-Quiet, 208-230V

MODEL: MDUO18024036

Advanced All-Electric Heating & Cooling for Year-Round Home Comfort

Step into the future of efficient, all-electric climate control with the MRCOOL® Universal Series 2–3 Ton DC Inverter Heat Pump Condenser. Designed to replace traditional HVAC systems, this ultra-high-efficiency unit delivers up to 20 SEER cooling and powerful heating—even in sub-zero temperatures down to -22°F.

Its sleek, compact design makes it ideal for zero-lot-line homes, strict noise-regulated areas, and rooftop or conventional installs. Featuring a whisper-quiet DC inverter rotary compressor and an energy-saving EEV metering device, it offers rapid heating/cooling with incredibly low operational sound levels of just 55 dB. Plus, it’s compatible with most third-party air handlers and smart thermostats (including Nest).

With no gas furnace required, the MRCOOL® Universal system gives homeowners a fully electric, eco-friendly option—delivering comfort, flexibility, and long-term savings.

Why You’ll Love It

✅ 2–3 Ton Capacity – Covers 24,000–36,000 BTU heating & cooling demand

✅ Up to 20 SEER Efficiency – For significant year-round utility savings

✅ -22°F Heating Capability – Engineered for extreme cold climates

✅ Energy Star & AHRI Certified – Trusted performance and verified ratings

✅ Universal Compatibility – Works with most thermostats and air handlers

✅ Ultra-Quiet Operation – Just 55 dB(A) for peaceful indoor comfort

✅ Slim Footprint – Ideal for tight spaces, rooftops, or noise-restricted zones

✅ DC Inverter Technology – Smooth, energy-efficient temperature control

✅ Pre-Charged with R-410A – Saves install time and complexity

✅ 10-Year Warranty – Registered limited coverage for added peace of mind

What’s Included:

• MRCOOL® Universal 2–3 Ton Inverter Heat Pump Condenser

• Pre-Charged with 148.8 oz R-410A Refrigerant

• Product Brochure

• Installation Manual

• AHRI Certificate


• Warranty Registration Info

Specifications

Specifications at a Glance

Attribute	Details
Voltage	208–230V / 1 Phase / 60 Hz
Cooling Capacity (BTU)	24,000
Heating Capacity (BTU)	24,000
SEER / SEER2	Up to 20 / 17
EER / EER2	12.5 / 12
HSPF / HSPF2	10.5 / 9
CFM	3000
Compressor Type	Inverter Rotary
Decibel Rating	55 dB(A)
Refrigerant Type	R-410A (Pre-Charged)
Operating Temp (Cool/Heat)	5°F–129.2°F (cool), -22°F–75.2°F (heat)
Line Set Size (Liquid/Suction)	3/8" / 3/4"
Max Line Set Length	164 ft
Energy Star Certified	Yes
AHRI Certified	Yes
ETL Certified	Yes
Warranty (Registered)	10-Year Limited Warranty

Room Size & BTU Coverage Guide (Universal Series)

BTU Rating	Tonnage	Recommended Room Size
18,000 BTU	1.5 Ton	600 – 900 sq. ft.
24,000 BTU	2 Ton	800 – 1,200 sq. ft.
36,000 BTU	3 Ton	1,200 – 1,500 sq. ft.
48,000 BTU	4 Ton	1,500 – 2,000 sq. ft.
60,000 BTU	5 Ton	2,000 – 2,500+ sq. ft. (open concept)

💡 Based on 8 ft ceilings, good insulation, and average sun exposure. Size up for rooms with high ceilings, large windows, or poor insulation.

Installation

Installation & Manuals

Product Brochure

Installation Manual

Warranty Document

AHRI Certificate

Energy Certificate
