MRCOOL® Universal Series 4–5 Ton DC Inverter Condenser – Up to 18 SEER | Ultra-Heat Technology

MODEL: MDUO18048060

Powerful, Energy-Efficient Climate Control with Universal Compatibility

Engineered for year-round comfort and significant energy savings, the MRCOOL® Universal Series 4–5 Ton DC Inverter Heat Pump Condenser is your high-capacity solution for larger homes and light commercial settings. With an impressive SEER rating of up to 18 and a variable-speed inverter compressor, this condenser delivers fast, quiet, and efficient heating and cooling—even in extreme outdoor conditions as low as -22°F.

Its slim, compact footprint makes it ideal for tight spaces and zero lot line installations, and its compatibility with virtually any third-party air handler or thermostat (including Wi-Fi-enabled models) offers unmatched flexibility.

The MDUO18048060 system features a smart ultra-heat inverter design that eliminates the need for a gas furnace, while still providing reliable warmth in harsh winters. Perfect for modern retrofits and upgrades, this condenser comes factory-charged and ready to integrate seamlessly with your existing or new system.

Why You’ll Love It

✅ Ultra-Heat Inverter Technology – Delivers reliable performance from -22°F to 129°F

✅ Efficient 4–5 Ton Output – Up to 18 SEER & 9 HSPF2 for lower utility bills

✅ Flexible Air Handler Pairing – Works with most 4T–5T air handlers and smart thermostats

✅ Whisper-Quiet Operation – Internal fan blade design reduces dB levels during use

✅ Slim Profile Design – Ideal for tight installations and zero lot line properties

✅ Pre-Charged & Ready – Saves time and cost during setup

✅ Smart Compatibility – Works with Wi-Fi and Nest-style thermostats

✅ ETL, AHRI, and Energy Star Certified – Meets top-tier performance standards

✅ No Gas Furnace Needed – Fully electric solution for eco-conscious homeowners

✅ 10-Year Registered Warranty – On compressor and parts for peace of mind

What’s Included:

• 4–5 Ton MRCOOL® Universal DC Inverter Condenser

• Factory Pre-Charged with R-410A Refrigerant

• Integrated Inverter Rotary Compressor

• Installation Manual

• Warranty Documentation

Specifications

Specifications at a Glance

Attribute	Details
SEER (up to)	18
SEER2	17
EER / EER2	11 / 11
HSPF / HSPF2	10.5 / 9
Tonnage	4–5 Ton
Cooling Capacity	48,000 BTU
Heating Capacity	48,000 BTU
Voltage / Phase / Cycle	208–230V / 1 Phase / 60 Hz
Max Fuse Breaker	45A
Min Circuit Ampacity	35A
Inverter	DC Inverter Rotary
Decibel Rating	58 dB(A)
Refrigerant Type	R-410A
Refrigerant Volume	220.48 oz
Operating Range (Cooling)	5°F – 129.2°F
Operating Range (Heating)	-22°F – 75.2°F
Line Set Length (Max)	164 ft / 5 bends
Liquid/Suction Line Size	3/8" & 3/4"
Certifications	ETL, AHRI, Energy Star
Warranty (Registered)	10-Year Compressor & Parts

Room Size & BTU Coverage Guide (Universal Series)

BTU Rating	Tonnage	Recommended Room Size
18,000 BTU	1.5 Ton	600 – 900 sq. ft.
24,000 BTU	2 Ton	800 – 1,200 sq. ft.
36,000 BTU	3 Ton	1,200 – 1,500 sq. ft.
48,000 BTU	4 Ton	1,500 – 2,000 sq. ft.
60,000 BTU	5 Ton	2,000 – 2,500+ sq. ft. (open concept)

💡 Based on 8 ft ceilings, good insulation, and average sun exposure. Size up for rooms with high ceilings, large windows, or poor insulation.

Installation

Installation & Manuals

Product Brochure

Installation Manual

Performance Data

Warranty Document

AHRI Certificate
